Amardeep Steel is a leading provider of Monel alloy 400 plates, offering high-quality nickel-copper alloy products known for their exceptional performance. Monel 400 plate is a strong copper-nickel alloy, combining approximately 67% nickel with 23% copper. It is highly resistant to seawater, steam, and various corrosive solutions, making it ideal for marine applications and chemical processing environments.
Our Monel 400 Plates are prized for their good ductility, corrosion resistance, and ability to withstand temperatures from cryogenic conditions up to 1000°F. These plates come in dimensions ranging from 200mm to 6000mm in length, 1000mm to 2000mm in width, and thicknesses between
0.3mm and 20mm. They are available in hot-rolled and cold-rolled finishes and can be cut, formed, ground, and polished to meet specific requirements. The alloy’s chemical composition includes 63% nickel, and 28% copper, with traces of iron, carbon, manganese, silicon, and sulfur.
Monel 400 Sheets and Shim Sheets offer excellent resistance to pitting and stress-corrosion cracking and are particularly effective against hydrochloric and hydrofluoric acids when de-aerated. However, they are vulnerable to nitric acid and ammonia. The material’s hardness is reflected by its NACE MR 175 score, and it maintains good mechanical properties even at subzero temperatures. Monel 400 can also be used in various tempers to enhance strength.
We also supply a range of Monel 400 Coils, including Monel DIN 2.4360, UNS N04400, GOST МНЖМц 28-2,5-1,5, JIS NW 4400, ASTM B127, and ASME SB127, tailored to meet different industrial needs. Our products are designed to provide solid performance in demandingenvironments and support various fabrication processes. For more details on sizes, finishes, and pricing, please contact us.
| Type | Plate, Sheet, Strip, Coils, Foils, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate |
| Grade | MONEL 400 - ALLOY 400 (66 Ni/34 Cu) - UNS N04400 |
| Alloy 400 Plate Length | 0-12mm or as required |
| Specification of Plate | ASTM B127 UNS N04400, ASME SB127, MSRR, BS, AMS 4544 sheet |
| 400 MonelPlate Width | 0-2500mm or as required |
| UNS N04400 Plate Thickness | 0.3 to 1200 mm or as required |
| ASTM B127 Alloy 400 Plate Process | Hot/ Cold Rolled |
| UNS N04400 Plate surface | No.1, No. 2D, No. 2B, BA, No.3, No.4, No.6, No.7, 2B, 2D, BA NO(8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled ASTM B127 Alloy 400 Plate, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Monel 400 | 2.4360 | N04400 | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 | NU-30M | NiCu30Fe |
| Thickness | Plate Weight per Unit Area | Density |
| 3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| Temperature | Mean Linear Expansion | Thermal Conductivity | Specific Heat® | Electrical Resistivity | |||||
| °F | °C | in/in/Fx10* | um/m °C | Btu-in/h/t2/PF | W/m °C | Btu/lb/°F | J/kge°C | ohm-circ ml/lt | |
| -320 | -200 | - | - | - | - | - | - | 205 | .360 |
| -300 | -180 | 6.1 | 11.1 | 113 | 16.5 | 0.050 | 223 | - | - |
| -200 | -130 | 6.4 | 11.4 | 130 | 18.2 | 0.078 | 320 | - | - |
| -100 | -70 | 6.7 | 12.1 | 139 | 19.8 | 0.088 | 378 | - | - |
| 70 | 21 | - | - | 151 | 22.0 | 0.102 | 427 | 307 | 0.511 |
| 200 | 100 | 7.7 | 14.2 | 167 | 24.0 | 0.105 | 445 | 322 | 0.537 |
| 400 | 200 | 8.6 | 15.2 | 193 | 26.9 | 0.110 | 459 | 337 | 0.559 |
| 600 | 300 | 8.8 | 15.7 | 215 | 30.1 | 0.114 | 470 | 346 | 0.574 |
| 800 | 400 | 8.9 | 16.1 | 238 | 33.4 | - | - | 355 | 0.587 |
| 1000 | 500 | 9.1 | 16.3 | 264 | 36.5 | - | - | 367 | 0.603 |
| 1200 | 600 | 9.3 | 16.6 | 287 | 39.4 | - | - | 379 | 0.620 |
| 1400 | 700 | 9.6 | 17.0 | 311 | 42.4 | - | - | 391 | 0.639 |
| 1600 | 800 | 9.8 | 17.4 | 335d | 45.5d | - | - | 403 | 0.658 |
| 1800 | 900 | 10.0 | 17.7 | 360d | 48.8 | - | - | 415 | 0.675 |
| 2000 | 1000 | 10.3d | 18.1 | - | - | - | - | 427 | 0.692 |
| Tolerance over and under nominal thickness t (mm) | ||||||||||
| Width w (mm) | 2.5<t <4.5 | 4.5<t <6.0 | 6.0<t <8.0 | 8.0<t <10.0 | 10.0<t <12.5 | 12.5<t <16.0 | 16.0<t <20.0 | 20.0<t <25.0 | 25.0<t <30.0 | 30<t <40.0 |
| w < 1200 | 0.20 | 0.23 | 0.30 | 0.32 | 0.35 | 0.80 | 0.80 | 0.80 | 1.0 | 1.4 |
| 1200< w <1500 | 0.20 | 0.25 | 0.30 | 0.35 | 0.38 | 0.80 | 0.80 | 0.90 | 1.0 | 1.4 |
| 1500< w <1800 | 0.20 | 0.28 | 0.32 | 0.38 | 0.40 | 0.80 | 0.80 | 0.90 | 1.1 | 1.5 |
| 1800< w <2100 | 0.20 | 0.30 | 0.36 | 0.40 | 0.45 | 0.80 | 0.80 | 0.90 | 1.1 | 1.5 |
| 2100< w <2400 | 0.80 | 0.80 | 0.80 | 0.80 | 0.80 | 0.90 | 1.0 | 1.1 | 1.5 | |
| 2400< w <2700 | 0.80 | 0.80 | 0.80 | 0.80 | 0.90 | 1.0 | 1.1 | 1.3 | 1.7 | |
| 2700< w <3000 | 0.80 | 0.90 | 1.0 | 1.0 | 1.0 | 1.1 | 1.3 | 1.4 | 1.8 | |
| Stocked Sizes | |
| Size (in inches) | Size (in mm) |
| .125" | 3.18mm |
| .134" | 3.40mm |
| .156" | 3.96mm |
| .187" | 4.75mm |
| .250" | 6.35mm |
| .312" | 7.92mm |
| .375" | 9.53mm |
| .500" | 12.7mm |
| .600" | 15.9mm |
| .750" | 19.1mm |
| .875" | 22.2mm |
| 1" | 25.4mm |
| 1.125" | 28.6mm |
| 1.250" | 31.8mm |
| 1.500" | 38.1mm |
| 1.750" | 44.5mm |
| 2" | 50.8mm |
| 2.500" | 63.5mm |
| 3" | 76.2mm |
ASTM B127 Alloy 400 Plate Imperial Dimensions
| Plate Surface finish | Gauge (in) | Width (max in) |
| 2B – Cold rolled, heat treated, pickled, skin passed Plate | 10–24 | 72* |
| 2D – Cold rolled, heat treated, pickled plate | 12–24 | 60 |
| BA Mexinox only | 18–28 | 48 |
| Polished plate (not brushed) | 11–24 | 60 |
| Temper rolled plate Mexinox only | 13–29 | 48 |
400 alloy Plate Metric Dimensions
| Plate Surface finish | Thickness (mm) | Width (max mm) |
| 2B – Cold rolled, heat treated, pickled, skin passed plate | 0.25–8.0 | 2032 |
| 2D – Cold rolled, heat treated, pickled plate | 0.4–6.35 | 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled plate | 0.4–8.0 | 2032 |
| 2R – Cold rolled, bright annealed plate | 0.25–3.5 | 1524 |
| 2H – Work hardened plate | 0.4–6.35 | 1524 |
| Polished, brushed plate | 0.5–4.0 | 1524 |
| Thickness | Plate Weight per Unit Area | Density |
| 3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| Condition of Supply | Heat Treatment (After Forming) | |||
| Annealed/Spring Temper | Stress relieve at 300-320°C (570-610°F) for 1 hour and air cool. | |||
| Condition | Approx Tensile Strength | Approx Service Temp. | ||
| Annealed | 400 - 600 N/mm2 | 58 - 87 ksi | -200 to +230°C | -330 to +445°F |
| Spring Temper | 850 - 1050 N/mm2 | 123 - 152 ksi | -200 to +230°C | -330 to +445°F |
| Property | Metric | Imperial |
| Density | 8.8 g/cm3 | 0.318lb/in3 |
| Melting point | 1350°C | 2460°F |
| Co-Efficient of Expansion | 13.9µm/m.°C (20-100°C) |
7.7x10-6 in/in.°F (70-212°F) |
| Modulus of rigidity | ||
| Modulus of elasticity | 105-120 kN/mm2 | 15230-17405 ksi |
