Nicrodur 400 Plate Supplier, Nicrodur 400, Nicrodur 400 Steel Plates Exporter, Nicrodur 400 Abrasion Resistant Steel Plates, Nicrodur 400 High Strength Steel Plates, Nicrodur 400 Wear Resistant Steel Plates Manufacturer in India.

Amardeep is a premier supplier, manufacturer, and exporter of Nicrodur 400 Wear Resistant Plates. These plates are specifically engineered to withstand heavy wear conditions in demanding applications. Nicrodur 400 Wear Resistant Plates exhibit exceptional properties, including outstanding wear resistance, excellent shock resistance, deep and consistent hardness, predictability in service, and a low carbon equivalency.
They are highly versatile and well-suited
for torch cutting, plasma cutting, and various fabrication methods. These plates find extensive use
across a broad spectrum of applications, thanks to their availability in different forms and
finishes, ranging from mechanically brushed to mill finishes. They excel in long-term usage,
particularly in high-surface-weight grinding conditions. Nicrodur 400 Wear Resistant Plates are
characterized by their wear and abrasion resistance, uniform thickness, and their ability to support
the construction of robust structures.
Nicrodur 400 Plates are widely employed in conveyors, loading buckets, bulldozers, crushers,
load-bearing components within the mining industry, wear parts for wood processing machinery, and
load-bearing elements in diverse applications, including dump trucks, loading shovels, lorries,
containers, and industrial trucks. These plates also serve essential roles in construction, mining,
chemical and petrochemical industries, fertilizer production, pulp and paper manufacturing, and the oil
and gas sector.
Our offering of Nicrodur 400 Plates encompasses a wide range of options, including different lengths,
shapes, sizes, dimensions, diameters, thicknesses, forms, standards, finishes, types, and
specifications. They are available in various forms, including hot rolled plates, cold rolled plates,
and polished plates, among others. To ensure their quality, we conduct numerous types of tests,
including hardness tests, toughness tests, flaring tests, chemical tests, mechanical tests, impact
tests, destructive tests, ultrasonic tests, strength tests, and positive material tests. Our commitment
to quality extends to providing top-notch packaging options, such as wooden boxes, bundles, plastic
wrap, and carton boxes, tailored to meet the specific packaging requirements of our clients.
Amardeep proudly stands as one of the leading suppliers and stockists of the highest quality Nicrodur
400 Plates. With our extensive experience, we specialize in supplying Wear Resistant Plates in custom
sizes, various materials, and across numerous dimensions. Our products are meticulously checked for
conformity to industry standards such as ASTM, DIN, ASME, MSS, EN, and JIS codes. Upon request, we can
engage certified inspection organizations to witness material reports, dimensions, and quality
compliance.
With over 40 years of experience, we possess an in-depth understanding of the steel industry, serving
major industries globally. Our Wear Resistant Plates are in regular demand by leading industrial units
and sectors, including chemical engineering, cement production, refinery facilities, oil and gas
operations, petrochemical industries, power generation, natural gas processing, and water disposal. Our
clients prefer our products due to their unique features, including durability, reliability, competitive
pricing, dimensional accuracy, and high-quality finishing.
Specification of Nicrodur 400 Plates
Item | Nicrodur 400 Plates |
---|---|
Grade | Wear Resistant Plates |
Thickness | 5mm to 150mm |
Width | 1,500mm to 2,500mm |
Length | 6,000mm to 12,000mm |
Heat Treatment | Rolling/Normalised, N, Q+T |
Surface Paint | PVDF, PE, HDP, SMP, EP |
Production Process | Hot rolled plate (HR) |
Nicrodur 400 Plates Chemical Composition
Plate Thickness [mm] | C max | Si max | Mn max | S max | P max | Cr max | Ni max | Mo max | B max | CEV max | |
NICRODUR 400 | |||||||||||
8 - 20 | 0,16 | 1,0 | 1,5 | 0,002 | 0,012 | 0,8 | 0,5 | 0,5 | 0,004 | 0,45 | |
(20) - 40 | 0,18 | 1,0 | 1,5 | 0,002 | 0,012 | 0,9 | 0,5 | 0,5 | 0,004 | 0,56 | |
(40) - 80 | 0,23 | 1,0 | 1,5 | 0,002 | 0,012 | 1,1 | 0,5 | 0,5 | 0,004 | 0,65 | |
NICRODUR 450 | |||||||||||
8 - 20 | 0,18 | 1,0 | 1,5 | 0,002 | 0,012 | 0,8 | 0,5 | 0,5 | 0,004 | 0,47 | |
(20) - 40 | 0,19 | 1,0 | 1,5 | 0,002 | 0,012 | 0,9 | 0,5 | 0,5 | 0,004 | 0,56 | |
(40) - 60 | 0,23 | 1,0 | 1,5 | 0,002 | 0,012 | 1,1 | 0,5 | 0,5 | 0,004 | 0,65 | |
(60) - 80 | 0,25 | 1,0 | 1,5 | 0,002 | 0,012 | 1,1 | 0,5 | 0,5 | 0,004 | 0,71 | |
NICRODUR 500 | |||||||||||
8 - 25 | 0,28 | 1,0 | 1,5 | 0,002 | 0,012 | 1,0 | 0,5 | 0,5 | 0,005 | 0,61 | |
(20) - 40 | 0,32 | 1,0 | 1,5 | 0,002 | 0,012 | 1,1 | 0,5 | 0,5 | 0,005 | 0,71 | |
(40) - 60 | 0,34 | 1,0 | 1,5 | 0,002 | 0,012 | 1,2 | 0,7 | 0,5 | 0,005 | 0,76 | |
(60) - 80 | 0,40 | 1,0 | 1,5 | 0,002 | 0,012 | 1,5 | 1,0 | 0,5 | 0,005 | 0,81 |
Nicrodur 400 Plates Mechanical Properties
Yield strength(minimal), Re [MPa] | Tensile strength, Rm [MPa] | Elongation (minimal), A5 [%] | |
NICRODUR 400 | 1200 | 1380 | 9 |
NICRODUR 450 | 1280 | 1450 | 9 |
NICRODUR 500 | 1500 | 1800 | 9 |
Nicrodur 400 Plates Hardness HBW
NICRODUR 400 | NICRODUR 450 | NICRODUR 500 |
360 - 440 | 420 - 477 | 460 - 540 |
Nicrodur 400 Plates Bending
Thickness | Transverse | Longitudinal | Transverse | Longitudinal | Springback | |
NICRODUR 400 | 8 ≥ t < 20 t ≥ 20 |
3,0 4,5 |
4,0 5,0 |
10,0 12,0 |
10,0 12,0 |
9 - 13 |
NICRODUR 450 | 8 ≥ t < 20 t ≥ 20 |
4,0 5,0 |
5,0 6,0 |
10,0 12,0 |
12,0 14,0 |
11 - 18 |
NICRODUR 500 | 8 ≥ t < 20 t ≥ 20 |
5,0 7,0 |
6,0 8,0 |
12,0 16,0 |
14,0 18,0 |
12 - 20 |
Maximum recommended preheat temperature
8 | 10 | 15 | 20 | 25 | 30 | 35 | 40 | 45 | 50 | 55 | 60 | 65 | 70 | 75 | 80 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
NICRODUR 400 | room | 75 | 100 | 175 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
NICRODUR 450 | room | 125 | 150 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
NICRODUR 500 | room | 175 | 200 |
Maximum recommended interpass temperature
NICRODUR 400 | 225 |
NICRODUR 450 | 225 |
NICRODUR 500 | 225 |
