Inconel 800 Seamless & Welded Pipes & Tubes Manufacturer, Supplier & Exporter
Amardeep Steel Centre is one of the leading manufacturers, supplier and exporter of Inconel 800 Pipes & Tubes. We focus on this family of nickel-iron-chromium alloys to provide the best solution even in the most demanding industrial applications. They are often talked about and identified interchangeably in the industry as Incoloy 800. The Inconel 800 Pipes & Tubes provide the strength and endurance needed for high-temperature service and resists oxidation while being resistant in neutral and reducing environments.
We offer a complete range of Inconel 800 Seamless & Welded Pipes & Tubes including round, square, rectangular, hydraulic and capillary. All of our Inconel 800 Pipes & Tubes are of the highest quality level to international standards such as ASTM B407 and ASME SB407. Our Inconel 800 Seamless Pipes are made using all of the latest manufacturing methods and, our Inconel 800 Welded Pipes are made using precision welding, all verified by MTCs (EN 10204/3.1B).
We pride ourselves to have the largest inventory of Inconel 800 Pipes and Tubes for immediate delivery. We have competitive pricing and we can ship all over the world! Whether you require standard Inconel 800 (UNS N08800), Incoloy 800H (UNS N08810) or Incoloy 800HT (UNS N08811) Amardeep Steel can provide you the right quality products and exceed your expectations.
What is Incoloy 800?
Inconel 800 (UNS N08800, Werkstoff 1.4876) is an alloy made from nickel, iron and chromium that is made to perform excellently in rigorous, extreme temperature conditions. Its Inconel 800 chemical composition that is Primarily 30 to 35% Nickel and 19–23% Chromium makes it very stable. That's the reason why the Incoloy 800 Tube is mostly used in demanding fields like nuclear engineering, petrochemicals and power production.
Understanding the Incoloy 800 Series: 800 vs 800H vs 800HT
Even though they are all made from the same basic alloy, these three grades of Inconel 800 Pipes & Tubes are very different in major ways that are meant to work best in harsh thermal environments.
This is Incoloy 800 (UNS N08800): At temperatures up to 1100°F (593°C) this is the base metal that is very resistant to oxidation and carburization. Its nickel presence makes it very durable to chloride stress corrosion cracking that makes Inconel 800 Welded Tubes ideal for regular use.
Incoloy 800H (UNS N08810): This is a change to Alloy 800 that consists of higher carbon content (0.05% to 0.10%) and bigger grains. Because of these changes Inconel 800 Seamless Pipes have much better creep and thermal fatigue failure qualities making it ideal for service above 1100°F (593°C).
Incoloy 800HT (UNS N08811): This grade improves Alloy 800H even more by adding controlled amounts of Titanium and Aluminum (0.85% to 1.20% combined). Because this chemical change gives the best creep and rupture strength, it is the best choice for the toughest elevated temperature structural operations that use Inconel 800 Seamless Tubes.
Table of Contents
- Specifications for Incoloy 800 Pipes & Tubes
- Incoloy 800 Chemical Composition
- Mechanical Properties of Inconel 800H Pipes
- Incoloy 800/ 800H/ 800HT Pipes & Tubes Equivalent Grades
- Incoloy 800 Pipe Pressure Rating
- Incoloy 800 Pipe Dimensions and Schedule Chart
- Incoloy 800 Pipe Weight Chart
- Types of Incoloy 800 Pipes & Tubes
- Applications of Inconel 800 Pipes & Tubes
- Why Choose Amardeep Steel for Your Inconel 800 Pipes & Tubes?
- Related Products
Specifications for Incoloy 800 Pipes & Tubes
|
Attribute |
Details |
|---|---|
|
Seamless Pipe Standards |
ASTM B407, ASTM B829 / ASME SB407, SB829 |
|
Welded Pipe Standards |
ASTM B514, B775 / ASME SB514, SB775 |
|
Other Standards |
BS 3074NA15, DIN 17459, VdTüV 412 & 434, ISO 6207 |
|
Manufacturing Process |
Seamless, ERW, Welded, Fabricated, Cold Drawn, Hot Finished |
|
Surface Finish |
Annealed & Pickled (AP), Bright Annealed (BA), Polished (No.4, No.8 Mirror), Cold Drawn |
|
Stock Brands |
Nippon Steel, Sumitomo, Sandvik, Schoeller-Bleckmann, Tubacex |
|
HS Code |
Hot Rolled: 73044900, Cold Finished: 73044100 |
Incoloy 800 Chemical Composition
|
Grade |
C |
Ni |
Cr |
Fe |
Al + Ti |
Mn |
Si |
|---|---|---|---|---|---|---|---|
|
Incoloy 800 |
0.10 max |
30.0-35.0 |
19.0-23.0 |
39.5 min |
0.15-0.60 |
1.5 max |
1.0 max |
|
Incoloy 800H |
0.05-0.10 |
30.0-35.0 |
19.0-23.0 |
39.5 min |
0.15-0.60 |
1.5 max |
1.0 max |
|
Incoloy 800HT |
0.06-0.10 |
30.0-35.0 |
19.0-23.0 |
39.5 min |
0.85-1.20 |
1.5 max |
1.0 max |
Mechanical Properties of Inconel 800H Pipes
| Property | Value |
|---|---|
| Tensile Strength | 520 MPa (75,000 psi) |
| Yield Strength (0.2%) | 205 MPa (30,000 psi) |
| Elongation | 30% |
Incoloy 800/ 800H/ 800HT Pipes & Tubes Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR | BS | GOST | EN | OR |
|---|---|---|---|---|---|---|---|---|
| Incoloy 800 | 1.4876 | N08800 | NCF 800 | Z8NC32-21 | NA 15 | ЭИ670 | X10NiCrAlTi32-20 | XH32T |
| Incoloy 800H | 1.4958 / 1.4876 | N08810 | NCF 800H | Z8NC33-21 | NA 15(H) | ЭИ670 | X5NiCrAlTi31-20 | XH32T |
| Incoloy 800HT | 1.4859 / 1.4876 | N08811 | NCF 800HT | - | NA 15(HT) | ЭИ670 | X8NiCrAlTi32-21 | XH32T |
Incoloy 800 Pipe Pressure Rating
|
OD (in) |
Wall: 0.035" |
Wall: 0.049" |
Wall: 0.065" |
Wall: 0.083" |
|---|---|---|---|---|
|
1/4" |
4,800 |
7,000 |
9,500 |
- |
|
3/8" |
3,100 |
4,400 |
6,100 |
- |
|
1/2" |
2,300 |
3,200 |
4,400 |
- |
|
3/4" |
- |
2,200 |
3,000 |
4,000 |
|
1" |
- |
- |
2,200 |
2,900 |
Incoloy 800 Pipe Dimensions and Schedule Chart
|
NPS (in) |
OD (in) |
Sch 10S (in) |
Sch 40S (in) |
Sch 80S (in) |
|---|---|---|---|---|
|
1/2" |
0.840 |
0.083 |
0.109 |
0.147 |
|
3/4" |
1.050 |
0.083 |
0.113 |
0.154 |
|
1" |
1.315 |
0.109 |
0.133 |
0.179 |
|
1 1/2" |
1.900 |
0.109 |
0.145 |
0.200 |
|
2" |
2.375 |
0.109 |
0.154 |
0.218 |
|
3" |
3.500 |
0.120 |
0.216 |
0.300 |
|
4" |
4.500 |
0.120 |
0.237 |
0.337 |
|
6" |
6.625 |
0.134 |
0.280 |
0.432 |
|
8" |
8.625 |
0.148 |
0.322 |
0.500 |
|
10" |
10.750 |
0.165 |
0.365 |
0.500 |
|
12" |
12.750 |
0.180 |
0.375 |
0.500 |
Incoloy 800 Pipe Weight Chart
|
NPS (in) |
OD (mm) |
Sch 40 Weight ( |
Sch 80 Weight ( |
|---|---|---|---|
|
1/2" |
21.3 |
1.27 |
1.62 |
|
3/4" |
26.7 |
1.69 |
2.20 |
|
1" |
33.4 |
2.50 |
3.24 |
|
1 1/2" |
48.3 |
4.05 |
5.41 |
|
2" |
60.3 |
5.44 |
7.48 |
|
3" |
88.9 |
11.29 |
15.27 |
|
4" |
114.3 |
16.07 |
22.32 |
|
6" |
168.3 |
28.26 |
42.56 |
|
8" |
219.1 |
42.55 |
64.63 |
|
10" |
273.0 |
60.31 |
81.53 |
|
12" |
323.9 |
79.73 |
108.97 |
Types of Incoloy 800 Pipes & Tubes
Applications of Inconel 800 Pipes & Tubes
- Petrochemical Furnaces: Ethylene and steam methane reformer pigtails and headers.
- Heat-Treating Equipment: Radiant tubes, muffles, retorts, and fixtures.
- Power Generation: Superheater and reheater tubing in power plants.
- Chemical Processing: Production of nitric acid, vinyl chloride, and other chemicals.
- Industrial Heating: Components for industrial furnaces and boilers.
Why Choose Amardeep Steel for Your Inconel 800 Pipes & Tubes?
- Expert Manufacturer & Supplier: We are a direct manufacturer and specialized supplier of the full Inconel 800, 800H, and 800HT range.
- Competitive Price: Our large-scale operations and extensive stock allow us to offer the most competitive price in the market.
- Complete Range: We stock a vast inventory of Inconel 800 Seamless & Welded Pipes & Tubes in all major sizes and schedules.
- Global Exporter: As an experienced exporter, we ensure seamless logistics, proper packaging, and complete documentation for all international deliveries.
- Quality Guarantee: All our materials are sourced from approved mills and are supplied with full certification and traceability, ensuring you receive only the highest quality Inconel 800 Pipes & Tubes.
Related Products
- Inconel Pipes & Tubes
- Inconel 600 Pipes & Tubes
- Inconel 601 Pipes & Tubes
- Inconel 625 Pipes & Tubes
- Inconel 690 Pipes & Tubes
- Inconel 718 Pipes & Tubes
- Inconel 825 Pipes & Tubes
- Inconel Plates, Sheets & Coils
- Inconel Bars, Rods & Wires
- Inconel Forged Fittings
- Inconel Buttweld Fittings
- Inconel Flanges
- Inconel Fasteners
Get a Competitive Price for Incoloy 800 Pipes & Tubes Today!
For your requirements of high-quality, certified Incoloy 800, 800H, or 800HT Pipes & Tubes, contact Amardeep Steel Centre. Our expert team is ready to provide you with a competitive quote and technical assistance for your project.
