EN 10210-1 Grade S275J2H cold worked pipes and tubes are designed to perform under elevated temperatures, with a melting point exceeding 1480 degrees Celsius. These pipes and tubes offer an elongation rate of 17 to 20%. They have a minimum yield strength of 265 MPa and tensile strength ranging from 410 MPa to 580 MPa.
EN 10210-1 Grade S275J2H Carbon Steel Seamless Pipes and Tubes are composed of 0.2% carbon, 1.5% manganese, phosphorus, and sulfur. This versatile material can be used as low and high temperature carbon steel, as well as low and high temperature alloy steel, depending on the composition and grade. The EN S275J2H Square Pipe, along with round, rectangular, and hydraulic pipe types, are widely utilized in oil and gas, petroleum, petrochemical, and general engineering applications.
The Hot Finish EN 10210 S275J2H Square Hollow Section is used as structural components in engineering applications. These pipes can be welded using most conventional methods. For more information, pricing, or to place an order for SHS Pipe & Tube and other products, please feel free to contact us.
Amardeep Steel is a supplier of EN 10210-1 Grade S275J2H Pipes, known for their durability and high performance under elevated temperatures. S275J2H pipes are made from carbon steel and adhere to the EN 10210-1 standard, ensuring they meet high-quality standards. They have a melting point above 1480 degrees Celsius, making them suitable for high-temperature applications.
EN 10210-1 Grade S275J2H pipes are characterized by their elongation rates between 17% and 20%, which indicates their ability to stretch before breaking. They have a minimum yield strength of 265 MPa and tensile strengths that range from 410 MPa to 580 MPa, providing a balance of strength and flexibility.
| Property | Specification |
|---|---|
| Material Grade | EN 10210-1 Grade S275J2H |
| Common Names | Mild Steel Pipes, Low Carbon Steel Pipes |
| Carbon Content | Maximum 0.20% |
| Manganese Content | 0.50 – 1.40% |
| Formability | Easy to form and shape |
| Manufacturing Standard | EN Specification |
| Commercial Reference | CS Pipes (Carbon Steel Pipes), MS Pipes (Mild Steel Pipes) |
| Hardness | Not as hard as high carbon steel pipes; carburizing can increase surface hardness |
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
|---|---|---|---|---|---|---|---|---|---|
| max 0.20 | – | max 1.50 | 0.035 | 0.035 | – | – | – | – | – |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 410 | 560 | – | 22 | ||
| Component length (mm) | OD 30-100 mm | OD 100-254 mm |
|---|---|---|
| 10-100 | + 1.0/- 0 | + 2.0/- 0 |
| 100-600 | + 2.0/- 0 | + 3.0/- 0 |
| 600-1200 | + 3.0/- 0 | + 4.0/- 0 |
| 1200-5000 | + 5.0/- 0 | + 6.0/- 0 |
| Outer diameter and wall Thickness | |||
|---|---|---|---|
| Execution | Size Range | OD Tolerance | Wall tolerance |
| Hot-rolled Tube | OD – 80 mmOD > 80 mmWall < 12 mmWall - 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm |
| Hot-rolled peeled tube | All sizesWall < 12 mmWall - 12 mm | + 0.25/- 0 mm | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) |
| Cold Worked tubecold-rolled or cold-drawn | OD < 40 mmOD 40 - 80 mmOD > 80 Wall Thickness< 6 mm Wall Thickness6 - 8 mm Wall Thickness > 8 | + 0.30/- 0 mm*+ 0.35/- 0 mm*+ 0.40/- 0 mm* |
± 0.30 mm± 0.35 mm± 0.40 mm |
