Difference between low-alloy steel & high-alloy steel

by Amardeep Steel

Posted on July 5, 2021 at 11:30 am

alloy steel

In general, there are certain variations occur between low alloy steel and high alloy steel. Low alloy steel is nothing but alloy steel whereas the high alloy steel is stainless steel with alloy mixture. We, Amardeep Steel Centre are providing both high-quality low alloy steel and high alloy steel. Below you can find the difference between them.

What is Low Alloy Steel?

Low alloy steel is a type of alloy steel that is better than carbon steel in many ways. For instance, this alloy has better mechanical properties than carbon steel and is more resistant to corrosion. Less than 0.2% of low alloy steel is made up of carbon. Ni, Cr, Mo, V, B, W, and Cu are all elements that can be mixed with carbon.

Low Alloy Steel

Most of the time, heat treatment and tempering are part of the process of making these alloy steels (for normalizing). But it usually includes cooling and heating now. Also, almost all types of low alloy steel can be welded. But sometimes the material needs to be treated before or after the weld (to avoid cracking).

Some advantages of low alloy steel include the followings:

  1. Yield strength
  2. Creep strength
  3. Oxidation resistance
  4. Hydrogen resistance
  5. Low-temperature ductility, etc.

Low alloy steel is a sort of steel that has different materials added to it; however alternate materials commonly make up a little measure of the whole steel. Through the expansion of specific alloys, low-alloy steel have exact concoction pieces and give preferred mechanical properties over numerous traditional gentle or carbon steels. Steel ordinarily is an alloy comprising of carbon and iron, however low alloy steel regularly includes hard metals, for example, nickel and chromium. These alloys normally include one to five percent of the steel's substance and are included based their capacity to give a particular trait. This steel, for the most part, is hard and hard to weld, yet the steel's qualities can be changed relying upon the incorporations. Luckily, in spite of the expansion of these components, low-alloy steel aren't really hard to weld. This most regularly is utilized to make huge funnels for the oil business; however, it additionally can be utilized for development and military purposes. In any case, knowing precisely what sort of low-alloy steel you have is basic to accomplishing great weld honesty, as is legitimate filler metal choice. Steel itself is an exceptionally essential alloy that uses a blend of iron and carbon.

What is High Alloy Steel?

High alloy steel is a type of alloy steel that has more than 5% of alloying steel. The elements that make high alloy steel different from low alloy steel are chromium and nickel. Stainless steel is a well-known type of this kind of material.

 High Alloy Steel

Chromium gives steel a thin layer of oxide on the surface. We call it the "latent layer" because it makes it take longer for the metal to rust. In addition, manufacturers usually add a lot of carbon and manganese to steel to make it austenitic. This material is also more expensive than low alloy steel.

High Alloy Steel is basically an alloy of Iron which consists of Chromium of 10.5%. High alloy steel likewise has over 10% mixture of the alloy. Chromium delivers a thin layer of oxide on the surface of the steel known as the latent layer. They are smidgen costly than low-alloy steel. This keeps any further consumption of the surface. High level of carbon and manganese are added to give austenitic nature to steel. Expanding the measure of Chromium gives an expanded protection from erosion. Due to the high chromium content, high-alloy steel can oppose consumption.High-alloy steel additionally contains shifting measures of Silicon, Manganese, and Carbon. Utilized for benefit in extraordinary hot gasses and fluids and at high temperatures Different components, for example, Molybdenum and Nickel might be added to grant other helpful properties, for example, improved formability and expanded consumption protection.

What is the Difference Between Low Alloy Steel and High Alloy Steel?

Both low alloy steel and high alloy steel are better than carbon steel. But the biggest difference between low alloy steel and high alloy steel is that low alloy steel has less than 0.2% alloying element and high alloy steel has more than 5% alloying element. Low alloy steel is made up of iron, carbon (less than 0.2%), and other alloying elements like Ni, Cr, Mo, V, B, W, and Cu. High alloy steel, on the other hand, is made up of iron, chromium, nickel, carbon, manganese, etc.

The below infographic provides more information regarding the difference between low alloy steel and high alloy steel .

Difference Between Low Alloy Steel and High Alloy Steel
High Alloy Steel Grades

  • ASTM A335 Gr P1, P5, P11, P22, P9, P91 Pipes
  • ASTM A234 Gr.WP5, WP9, WP11 Fittings
  • ASTM A182 F5, F9, F11 Forging, Flanges, and Forged Fittings

Low Alloy Steel Grades

Steel category ASTM / ASME standard
  Low Alloy Steel Plate Low Alloy Steel Pipe SMAW Electrode/ Rod Flux Cored Wires
0.5%Mo A204 Grade A,B,C A336 Grade F1 A209 Grade T1 A335 Grade P1 GL76/78A1 GMX 811A1
0.5%Cr-0.5%Mo A387 Grade 2 CI.1,2 A213 Grade T2 A335 Grade P2 GL86/88B1
1.25%Cr-0.5%Mo A387 Grade 12 Cl.1,2 A387 Grade 11 CI.1,2 A336 Grade F11 A213 Grade T11, 12 A335 Grade P11, 12 A182 Grade F11 GL86/88B2 GMX 811B2
2.25%Cr-1.0%Mo A387 Grade 22 CI.1,2 A336 Grade F22 A213 Grade T22 A335 Grade P22 A182 Grade F22 GL86/88B3 GMX 911B3
5.0%Cr-0.5%Mo A387 Grade 5 CI.1,2 A335 Grade P5 GL86/88B6
9.0%Cr-1.0%Mo A387 Grade 9 CI.1,2 A335 Grade P9 GL86/88B8

There are several important differences between low alloy and high alloy steels. The major uses for low alloy steels are in the aerospace, automotive, and jewelry industries due to their ability to be stamped quickly and efficiently. While high alloy alloys can be stamped more rapidly and easily, they are less expensive than their lower alloy counterparts and usually provide a greater amount of durability.

There is a big difference in the properties between low alloy and high alloy steel which Amardeep steel would like to highlight for all the potential buyers as we help in letting you make the right choice. The composition of the steel is what makes it different. As you will see in this article, there are some common similarities between low alloy and high alloy steels, but there are also some key differences in properties that affect how they hold up in handling and using metal tools and equipment.
